Technical Specifications
✔8 German made V 400 type suction cups.
✔When the outer rubberized arms are removed, there are 4 tires in the middle. In this way, it can carry the smallest 1000 x 1800 glasses.
✔With 24 Volt battery, it makes vacuum by radio control, hydraulically automatically tilts and automatically rotates by means of reducer.
✔Vacuum system, double tank, double safety valve, double vacuum gauge and double vacuum pump.
✔The arms of the apparatus extend telescopically and the closed size from tire to tire is 1720 – 3440 x 950 mm.
✔Glass sizes it can carry: 1000 x 1800 mm. to 3210 x 10.000 mm.
✔There is a valve on each suction cup so that it can work in a single row.
✔Vacuum carrier dimensions: 1720-4020 x 1000 x 1600 (h) mm. weight: 693 kg.
✔There is a wheeled trolley at the bottom of the machine for easy operation.
✔The tires can move in multifunctional angular motion.
✔Maximum carrying capacity is 2500 kg.
✔Our device is CE, ISO 9001-2000, EN 13155: 2003 + A2 norms, fully independent double vacuum circuit.
