Technical Specifications
✔24 pieces V300 type suction cups located the machine.
✔Suction cup rubbers will be manufactured to catch oily surface.
✔It makes vacuum with 380 V three phase electric pump.
✔Radio ( remote ) controlled hold and release function.
✔It never leaves the material through the automatic safety system.
✔When the electricity is cut, the safety tank continues to vacuum.
✔Operator friendly steering arm with the controls is of the motorcycle type.
✔Machine dimensions : 900 x 6.000 – 10.000 mm. ( When the arms are extended )
✔Carrying capacity is maximum 2000 kgs.
✔Vacuum indicators are available on the main carrier column and on the arms.
✔Suitable for sheet metal,glass or marble transportation.
✔The suction cup is designed so that the material is taken horizontally.
✔Sheet Sizes: Between 750 X 3.000 to 1.500 X 12.000 mm.
✔The machine has 4 independent vacuum circuits in accordance with EN 13155.
