Technical Specifications
✔Guide length : 3200 mm.
✔Working length : 2800 mm.
✔Manipülatör platform height: 300 mm.
✔Completely pneumatic controlled tilting and lifting.
✔Vacuum system works with 6-8 bar pressed air.
✔Four fixing belt lock over the platform.
✔Working height: 1800 mm. max
✔Air consumption : 50 lt / min
✔All controlls are located over the main arm.
✔Sizes : 3350 x 380 x 1600 ( h ) mm.
✔Machine weight : 300 kgs.
✔Lifting capacity : 100 kgs.
